LIN and CAN Bus Solutions

Taking Communication and Connectivity in Deeply Embedded Designs to the Next Level

Local Interconnect Network (LIN)

LIN/J2602 is a communication standard designed to

address low-cost networking within vehicles. LIN enables

a cost-effective communication network for lower speed

switch, smart sensor and actuator applications within

the vehicle where the bandwidth and versatility of CAN

is not required. LIN can be implemented on any PIC

microcontroller (MCU) with a UART or USART interface.

Microchip also offers a robust physical layer interface,

data link layer implementation, LIN compliant drivers and a

variety of development resources.

Standalone LIN Transceivers

The MCP2003/4(A) family of LIN transceivers offers a

standalone LIN transceiver option. Both parts meet LIN

bus specification versions 1.3, 2.0 and 2.1 and SAE

J2602. The transceivers' EMC/ESD performance is

among the best in the industry and meets all automotive

requirements. The MCP2003A is available in an industry

standard 8-pin SOIC pin out. The MCP2004A offers a

TXE/Fault pin which allows users the ability to disable the

transmitter in addition to providing data related to a fault

condition.

LIN Transceivers With Voltage Regulator

The MCP202XA family of LIN transceivers integrates the

LIN physical layer, 3.3V or 5V internal voltage regulator,

with a maximum output current of 70 mA.

The devices support LIN bus specification versions 1.3,

2.0 and 2.1 and SAE J2602 and are designed to meet

the stringent EMC/ESD requirements of the world’s auto

makers.

Microchip also offers the MCP2050 LIN Transceiver with

Voltage regulator, windowed watchdog timer and ratio

metric V BAT pin that allows for monitoring battery levels by

a MCU A/D converter.

Controller Area Network (CAN)

CAN is a serial communication protocol used extensively

for high speed embedded applications where noise

immunity and robustness is necessary. CAN protocol

supports speeds up to 1 Mbps and is highly fault-tolerant,

making it ideal for safety critical applications.

Microchip offers a complete line of products to meet

the needs of high-performance embedded applications

using the CAN protocol, including 8-, 16- and 32-bit

microcontrollers and 16-bit digital signal controllers with

integrated CAN, standalone CAN controllers, I/O expanders

and CAN transceivers.

CAN MCUs and DSCs

The 8-bit PIC18F66K80 family offers the industry's best

Sleep current of less than 20 nA, a wide operating voltage

range of 1.8 to 5.5V and an advanced touch sensing

interface. The 16-bit PIC24 and dsPIC33 families offer

higher density Flash memories and high temperature

operation of up to 150°C ambient. The 32-bit PIC32 family

offers higher performance and better peripheral integration

like Ethernet and USB.

At the heart of Microchip’s CAN offering is the

enhanced CAN module offered on-board many Microchip

microcontrollers. Key features include:

■ CAN 1.2, CAN 2.0A and CAN 2.0B support

■ 32 buffers for TX/RX

■ 32 acceptance filters

■ 4 acceptance mask filters

■ Time stamping

■ DMA support in 16-bit PIC24H and PIC32

microcontrollers and dsPIC33F digital signal controllers

■ DeviceNet? support

■ Legacy mode

Standalone CAN Controller

Microchip Technology’s MCP2515 is a stand-alone

Controller Area Network (CAN) controller that implements

the CAN specification, version 2.0B. It is capable of

transmitting and receiving both standard and extended

data and remote frames. The MCP2515 interfaces with

MCUs via an industry standard Serial Peripheral Interface

(SPI) and can be used as an easy method to implement

CAN in an existing system.

CAN Transceivers

The MCP2551 is a high-speed CAN device that serves as

the interface between a CAN controller and the physical

bus. The MCP2551 provides differential transmit and

receive capability for the CAN protocol controller and is

fully compatible with the ISO-11898 standard, including

24V requirements.

6

Connectivity Solutions

www.microchip.com/lin
